General

EA uniTFTm are a high-quality all-in-one implementation of the display, microcontroller unit, and touch screen. It is all users need to directly control their application and expedite development, prototyping, and deployment of their HMI/GUI. Design the HMI/GUI using the easy-to-use drag-and-drop uniTFTdesigner graphics development software


The EA uniTFTm series provides sophisticated graphical functions and intuitive menu control with its built-in instruction set. Thanks to the integrated instruction set and the Windows design software uniTFTDesigner, not only electronics specialists, but also experts in the field of design and user guidance are able to create the entire HMI.


The display modules are immediately ready for operation with 3.3 V, controlled via the built-in serial interfaces RS232, SPI, I²C or USB. The modules can be operated directly through the USB, too.

Object-oriented "programming", the wide set of commands, and the integrated but extensible Unicode fonts make "time-to-market" a breeze.


The EA uniTFT series, which forms the high-end market with larger modules, comes up with a very similar command set:

Currently are 3 different sizes available: 5" with 800x480 dots, 7" with 1024x600 dots and 10.1" with 1280x800 dots.


Advantage

Standard TFT

EA uniTFTm

Quality

Consumer

Non-consumer

Brightness

250cd

1000cd (typ.)

Viewing angle

Limited +/-50° (typ.)

Up to 340°

Color

TN with Gray inversion effect

IPS: no color shift

Touch

resistive

PCAP incl. controller

Interface

8-/16 Bit data bus

I²C or SPI or USB

Availability

Minimum order quantity

Ex stock

Longevity

1 year or more

Minimum of 8 years

Support

None unless high quantity

Bundled with product purchase

ce / EMC

None

Tested and certified

Software

Place dot by dot to create character or touch buttons

- High level commands included

- Graphics development software f.o.c.


To get an easy introduction to the use of the commands we have a collection of short explanatory videos with the uniTFT Academy online.

You are welcome to subscribe to our Youtube channel.
